The Linux File Hierarchy Structure (FHS) is a standardized directory layout for Unix-like operating systems. It defines the structure and contents of directories in the root filesystem, providing consistency across different Linux distributions. Understanding the FHS is crucial for efficient system administration, troubleshooting, and software development on Linux systems.
Root Directory (/)
The root directory is the top-level directory in the Linux filesystem hierarchy. All other directories and files branch out from this starting point.
Purpose: Serves as the primary hierarchy root and the root directory of the entire file system.
Contents:
- All essential directories (bin, etc, home, var, etc.)
- Mount points for other filesystems
Example: To list contents of the root directory:
ls /
/bin (Essential User Binaries)
Purpose: Contains essential command binaries that need to be available in single-user mode.
Contents:
- Basic system commands (ls, cp, mv)
- Shell interpreters (bash, sh)
Example: The ‘ls’ command is typically found here:
/bin/ls
/boot (Boot Loader Files)
Purpose: Contains files needed for booting the system.
Contents:
- Kernel images
- Initial RAM disk (initrd)
- Boot loader configuration (GRUB)
Example: Kernel image file:
/boot/vmlinuz-5.4.0-42-generic
/dev (Device Files)
Purpose: Contains device files that represent hardware devices and virtual devices.
Contents:
- Hard drive partitions (sda1, sdb1)
- Terminals (tty1, tty2)
- Null device (/dev/null)
Example: To write to the null device:
echo "discard this" > /dev/null
/etc (Configuration Files)
Purpose: Contains system-wide configuration files.
Contents:
- Network configuration
- User and group information
- System services configuration
Example: Network interfaces configuration:
/etc/network/interfaces
/home (User Home Directories)
Purpose: Contains personal directories for regular users.
Contents:
- User-specific files and folders
- Personal configuration files (dotfiles)
Example: A user’s home directory:
/home/username
/lib (Essential Shared Libraries)
Purpose: Contains libraries needed by the binaries in /bin and /sbin.
Contents:
- Shared library files (.so)
- Kernel modules
Example: C library:
/lib/x86_64-linux-gnu/libc.so.6
/media (Removable Media)
Purpose: Mount point for removable media like CD-ROMs, and USB drives.
Contents:
- Automatically mounted removable devices
Example: A mounted USB drive:
/media/username/USB_DRIVE
/mnt (Temporary Mount Points)
Purpose: Used for temporarily mounting filesystems.
Contents:
- Manually mounted filesystems
Example: Mounting a network share:
mount //server/share /mnt/networkshare
/opt (Optional Software)
Purpose: Contains add-on application software packages.
Contents:
- Third-party software installations
Example: A custom software installation:
/opt/myapp
/proc (Process Information)
Purpose: Virtual filesystem providing process and kernel information.
Contents:
- Process information
- System statistics
Example: To view CPU info:
cat /proc/cpuinfo
/root (Root User Home)
Purpose: Home directory for the root user.
Contents:
- Root user’s files and configurations
/run (Run-time Variable Data)
Purpose: Contains variable data files describing the running system since the last boot.
Contents:
- System information that is lost on reboot
- PID files
Example: System’s uptime:
cat /run/utmp
/sbin (System Binaries)
Purpose: Contains essential system binaries that are used for system administration.
Contents:
- System management commands
- Disk management utilities
Example: The ‘fdisk’ command:
/sbin/fdisk
/srv (Service Data)
Purpose: Contains data for services provided by the system.
Contents:
- Web server files
- FTP files
Example: Web server root:
/srv/www
/tmp (Temporary Files)
Purpose: Directory for temporary files.
Contents:
- Temporary files created by the system and users
- Cleared on system reboot
Example: Creating a temporary file:
echo "temp data" > /tmp/tempfile
/usr (User Programs)
Purpose: Contains user programs and data.
Contents:
- Non-essential binaries (/usr/bin)
- Libraries (/usr/lib)
- Documentation (/usr/share/doc)
Example: A user command:
/usr/bin/git
/var (Variable Data)
Purpose: Contains variable data files.
Contents:
- Log files (/var/log)
- Spool directories (/var/spool)
- Temporary files (/var/tmp)
Example: System log file:
/var/log/syslog
Recent Changes to FHS
The FHS has evolved to accommodate modern Linux systems. Notable changes include:
- Addition of /run directory: Introduced to store volatile runtime data, replacing /var/run and /var/lock.
- Consolidation of /bin, /sbin, /lib, and /lib64 into /usr: Some distributions now symlink these directories to their counterparts in /usr for better organization.
- Introduction of /sys: A virtual filesystem for kernel and device information, similar to /proc.
Understanding the Linux File Hierarchy Structure is essential for effective system management and troubleshooting. By following this standardized layout, Linux maintains consistency across distributions, making it easier for users, administrators, and developers to navigate and manage the system efficiently.
